Beschrijving
Features:
- Faithful reproduction of the legendary vintage German studio microphone
- Custom Heiserman HZ-series K47 capsule
- Custom wound, large, striped-core, American made Cinemag transformer
- Vintage polystyrene capacitors, and NOS (new old stock) FETs
- No electrolytic capacitors, over-spec’d components – it will last a lifetime
- Absolute workhorse, a desert-island microphone for professional studios and voiceover work
- Built in the USA
- Clean, clear, articulate, open sound. Low noise and high headroom and dynamic range
Specifications:
- Type: Condenser Microphone
- Capsule: HZ Series 34mm all-brass, dual-backplate K47
- Diaphragm: Dual-diaphragm, 6 micron, 24k gold sputtered Mylar (PET film)
- Power Supply: +48v Phantom Power (via XLR)
- Ground: Pin 1 XLR (required)
- Frequency Response: 20 Hz – 20 kHz
- Polar Pattern: Cardioid
- SPL: 136 dB (145 dB w/ Pad) @ <.5% THD
- Output Impedance: 200 Ω
- Amplifier Type: Field Effect Transistor
- Self Noise: <10 dB (no pad, no HPF)
- Output: Cinemag USA transformer balanced, pin 2 hot
- Body: Nickel electroplated, solid milled brass
- High pass filter: 75 Hz (-12dB down point)
- Pad: -10dB
- Connector: 24k gold plated XLR
- Mount: Self-contained stand swivel mount adapter
- Dimensions: Height: 210mm / 8.2 in.
- Width: 69mm / 2.7 in.
- Diameter: 63mm / 2.4 in.
